Bilaterally tipping bucket-tipping to the rear and to one side of the customer.

The conical tub ensure easy emptying of cohesive materials, smooth walls.

Hydraulic lift with hydraulic tailboard Zama.

The useful volume of 30.5 m ³.

Hopper window in the rear face.

Basic dimensions (mm)

max. length 9670

max. 2550

max. height with supers 3790

length of the loading area 7850

Platform width 2148/2248

volume (m³) 30.4 / 34 / 39.2

max. height when tilting backwards 8650/8834

max. height when tilting to the side 4162/4570

Weight (kg)

standby 8650/8770

useful permitted 24350/18350

Total max. 33000/27000

remedy

Class Type sprung, cushioned hydr.tridem

track width (mm) 1950/2000

Wheelbase (mm) 1525/1525

tire size 425 / 65R22,5, 445 / 65×22,5, 560 / 60×22,5, 560 / 60R22,5 550 / 60×22,5, 560 / 60R22,5 AR02

connecting dimensions disk Ø280 / Ø335

number / size wheel bolts 10xM22x1,5

brake drum 406×140 (414S)

Brake operation type with two

hand-operated mechanical parking brake

General parameters

maximum speed of 40 km / h

The equipment connecting shackle Ø 50 / K80

drawbar load (empty / full) 1100/3000

climbing ability 9 ° -10 °

12V voltage wiring

air pressure in the brake system minutes. 650 kPa

hydraulic system pressure of 18 MPa

Credits:

Model: Majky
Textura: Lexik CZ
Scéná?: LS JiraCz
Idea / Concept:
Tester: Marek BJ Ladis Jardis Smety Carlos Oriesok Modding
